1. H type broilers cage size

3 tiers, 96 capacity birds, 1.5m by 1.4m by 1.35m
4 tiers, 128 capacity birds, 1.5m by 1.4m by 1.75m

Corollary euipment: automatic feeding system, automatic manure removal system, drinking system
Surface treatment: hot dip galvanized

Material: q235 steel wire mesh

Lifespan: 25 to 30 years

2. Contact manager

Name: Mia liu

Whatsapp no: +8615233655036

Email: sales5@bestchickencage.com

3. H type chicken cage features

1. Broilers cage equipment is separated from the net and bottom net to effectively prevent the chicken from licking the anal phenomenon

2. The whole set of products adopts hot dipped galvanizing process and has long service life, Q235 material is large in elasticity and difficult to bend

3. The thickening structure of the front mesh wire is firmer, the structure is reasonable, and the energy consumption is low

4. Unique cage door design, the cage door space is larger, the position of chicken feeding can be arbitrarily changed, which effectively solves the crowded of chickens when eating, ensuring that the birds eat more evenly

4. Advantage of H type broiler cage

1. Very hygienic growing conditions, quick and easy cleaning, disinfection after every crop, reduce time between the crops

2. Higher density, three times higher stocking density as compared to floor production

3. Fully automatic system including a feeding system, drinking system, environment control system, manure cleaning system

4. Automatic feeder machine, automatic feeding, time saving, labor saving, saving feed

5. Automatic manure removal conveyor, daily manure removal, minimizes ammonia emissions in the house

6. Automatic control of ventilation and temperature

5. Cage system

1. Cage mesh: 300g per square meters hot dip galvanized or galvanized wire, lifespan is about 25 to 30 years. The smooth surface can reduce the rate of disease

2. Cage door: easy operation, friendly to worker and chicken

3. Feeder trough: pure PVC feeder trough.Strong, longer lifetime, easy to clean, healthy

4. Drinking line system: every cage has 5 nipple drinkers, and every nipple drinker is set up with water saving cup, to make sure that every chicks could drink enough water during brooding phase

6. Automatic feeding system

Automatic feeding machine: main part and hopper of feed crane are made from 275g hot dip galvanized sheets. The feeding system adopt the automatic control system, the machine can stop automatic

The feeding mouth with uniform material device can ensure feed be distribute evenly in the feed trough according to the setting of the feed, which can prevent the waste of feed

7. Manure removing system

The manure belt is made of high strength PP composite with friction resistance and corrosion resistance.It has long lifespan, which is not easy to be deformed. Manure cleaning scraper is made from stainless steel plate. The part in contact with manure cleaning belt is made from PE plastic to prevent scratching

8. Environment control system

Ventilation fan system: ventilation fan system controls poultry house humidity for your chickens, ensuring your broilers provide maximum production

Cooling pad system: when the air goes through cooling pads, the heat will be taken down by the evaporation of water. So the air will be cooled before

Environmental control equipment: the environmental control system monitors constantly based on temperature and humidity sensor data. It controls the cooling fans,cooling pads and the clear story automatically by a microcomputer integrated system

9. Poultry farm site selection

The selection of chicken farm address should not only consider the requirements of production on the surrounding environment, but also try to avoid the impact of chicken farm odor and feces on the environment. The following factors should be considered

1. Terrain and landform: the site of the chicken farm should be dry and flat

2. Geography and transportation: 20 km away from big cities, 15 km away from residential areas and other poultry farms, chicken farms should be more than 2 km away from commercial chicken farms, and there is no noise and chemical smell of factories nearby. It is 400 meters away from the main highway and 100 meters above the secondary highway, but the transportation should be convenient and close to the highway. The self built highway can reach the site to transport raw materials and products, and the site should be close to the consumption place and the source of feed

3. Soil and water: the soil should meet the requirements of chicken farm sanitation and epidemic prevention and construction requirements, adequate water, good water quality

4. Power supply: in addition to the 24 hours power supply for the incubation room, the lighting of the chickens must also have power supply. Therefore, for larger chicken farms, it is necessary to have standby power supply, such as double line power supply or generator

5. Open house, as we all know, Nigeria weather is hot and lot rain, in order to ensure good ventilation, open farm is recommended

10. Our service

1. We have more than 20 years of production experience, meanwhile our products have been improved

2. We have the professional designers help you design the chicken house and provide you with free chicken house construction drawing paper

3. We have the professional knowledge of breeding, we can give you more advice

4. Our products have passed ISO 9001 quality Certification, our quality more secure

5. We can guarantee 5 years quality about the plastic accessories, we can free replace it for you if there are any quality questions within 5 years

6. Manager contact is +8615233655036

11. Our company

Hebei Best Machinery And Equipment Co,Ltd. was established in 1996, growing fast from a small machinery factory into today well reputed professional poultry equipment manufacturer. Over 19 years, we have been working on development and manufacturer of automated poultry rearing equipment. Now we pride ourselves on supplying global poultry farmers with efficient, excellent quality and durable products for poultry production. Our product line has been expanded to include a diversity of poultry cages for layers, pullets and broilers as well as a wide range of feeding, drinking, egg collection, manure removal and climate control systems
