A type automatic chicken layer battery cage system

Type: A type

Tiers: 3 tier or 4 tier chicken cage

Capacity of each unit cage: 120 birds or 160 birds

Applicable industries: poultry farms

Use: layer chicken

Specification: 2.2meters, 2.4meters width, 1.65meters high of 3 tier

2.2meters, 2.4meters width, 1.95meters high of 4 tier

Raw material: international Q235 bridge steel

Anti corrosion treatment process: aluminum-zinc alloy, hot-dip galvanized

Lifetime: 15 to 20 years

Automatic egg collection system: eggs are transported to the egg collection room by egg-picking belts, ensuring less human contamination and damage

Automatic feeding system: no human operation is required in the feed transportation process, and the whole process is fully automated

Automatic drinking system: it can provide clean and stable water for poultry and reduce the risk of disease infection in the flock

H type frame automatic layer battery cage system

Type: H type

Tiers: 3 to 8 tiers

Applicable industries: poultry farms

Use: layer chicken

Raw material: international Q235 bridge steel

Anti-corrosion treatment process: aluminum-zinc alloy, hot-dip galvanized

Lifetime:15 to 20 years

H-frame battery layer chicken cage system has a high degree of automation and high density. It can effectively improve the utilization rate of chicken house and land, reduce the cost of feeding, and effectively improve labor productivity. House using the battery cage systems can be left unattended. And keep the flocks completely separate to prevent the spread of disease. High-density raising, saves land and investment. Suitable for closed chicken house. Automatic control of ventilation and temperature can meet the requirement of the birds

What other farm equipment needed for automatic chicken cage farm

12,000 birds layer chicken farm equipment lists in Nigeria, Ghana

1. A type layer chicken cage system: 99 sets A type 3 tier layer cage

2. Automatic feeding machine: 3 set automatic feeding hopper system for 3 rows

3. Scraper manure removing system: one set with 3 scrapers work for 3 rows

4. Automatic egg collecting system: 3 sets in total, 1 set work for one row

5. Ventilation system: 1 set, cooling fan, cooling pad and small side windows

6. Automatic environmental controlling system: 1 set

7. Chicken house size advice: 82meters long, 12meters width and 3.5meters high

8. Chicken house walking space: 4.7meters leave between cages and front wall, 1.2meters leave for walking space between cages and cages

9. Feed mill machine with mixer and grinder function together to produce chicken feeds

10. Silo to store chicken feeds

15,000 birds layer chicken farm equipment lists in Uganda, Kenya, Zambia

1. A type layer chicken cage system: 126 sets A type 3 tier 120 capacity layer cage

2. Automatic feeding machine: 3 set automatic feeding hopper system for 3 rows

3. Scraper manure removing system: one set with 3 scrapers work for 3 rows

4. Automatic egg collecting system: 3 sets in total, 1 set work for one row

5. Ventilation system: 1 set, cooling fan, cooling pad and small side windows

6. Automatic environmental controlling system: 1 set

7. Chicken house size advice: 102meters long, 12meters width and 3.5meters high

8. Chicken house walking space: 4.8meters leave between cages and front wall, 1.2meters leave for walking space between cages and cages

9. Feed mill machine with mixer and grinder function together to produce chicken feeds

10. Silo to store chicken feeds

17,600 birds layer chicken farm equipment lists in Tanzania, South Africa

1. A type layer chicken cage system: 147 sets A type 3 tier 120 capacity layer cage

2. Automatic feeding machine: 3 set automatic feeding hopper system for 3 rows

3. Scraper manure removing system: one set with 3 scrapers work for 3 rows

4. Automatic egg collecting system: 3 sets in total, 1 set work for one row

5. Ventilation system: 1 set, cooling fan, cooling pad and small side windows

6. Automatic environmental controlling system: 1 set

7. Chicken house size advice: 117meters long, 12meters width and 3.5meters high

8. Chicken house walking space: 4.6meters leave between cages and back wall, 1.2meters leave for walking space between cages and cages

9. Feed mill machine with mixer and grinder function together to produce chicken feeds

10. Silo to store chicken feeds

20,000 birds layer chicken farm equipment lists in Zimbabwe, Cameroon

1. A type layer chicken cage system: 126 sets A type 4 tier 160 capacity layer cage

2. Automatic feeding machine: 3 set automatic feeding hopper system for 3 rows

3. Scraper manure removing system: one set with 3 scrapers work for 3 rows

4. Automatic egg collecting system: 3 sets in total, 1 set work for one row

5. Ventilation system: 1 set, cooling fan, cooling pad and small side windows

6. Automatic environmental controlling system: 1 set

7. Chicken house size advice: 102meters long, 12meters width and 3.5meters high

8. Chicken house walking space: 4.8meters leave between cages and front or back wall, 1.2meters leave for walking space between cages and cages

9. Feed mill machine with mixer and grinder function together to produce chicken feeds

10. Silo to store chicken feeds

25,000 birds layer chicken farm equipment lists in Benin, Gambia, Sudan

1. A type layer chicken cage system: 160 sets A type 4 tier 160 capacity layer cage

2. Automatic feeding machine: 4 set automatic feeding hopper system for 4 rows

3. Scraper manure removing system: 2 sets with 2 scrapers work for 4 rows

4. Automatic egg collecting system: 4 sets in total, 1 set work for one row

5. Ventilation system: 1 set, cooling fan, cooling pad and small side windows

6. Automatic environmental controlling system: 1 set

7. Chicken house size advice: 98meters long, 14.6meters width and 3.5meters high

8. Chicken house walking space: 5meters leave between cages and front or back wall, 1meters leave for walking space between cages and cages

9. Feed mill machine with mixer and grinder function together to produce chicken feeds

10. Silo to store chicken feeds
